Description
Brand new aftermarket stator + rotor + ignition coil
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- All products shipped are tested
*All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Stator :
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Connector included
- Rubber grommet included
Specifications:
Stator Dimensions :
Length of wires stator to grommet : 75 mm
Length of wires grommet to plug : 148 mm
Other specifications :
Number of wires : 2
Number of plugs : 2
Alternator : Black to ground = 4.5 ohms +-20%
External Ignition Coil :
Distance between fixation holes: 20 mm
Wire Length: 51 mm
Resistance: 6.1 ohms
Rotor Dimensions :
Interior widest diameter : 12 mm
Interior narrowest diameter : 12 mm
Interior length : 19 mm
Exterior Diameter: 36 mm
Fixation holes center to center: 23 mm
Warning:
Please Note : If you have an older KTM50 with black “Morini Franco” engine this kit will not fit on you vehicle
Battery condition is extremely important. No stator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.
