Description
Brand new aftermarket Stator
- Direct replacement to your original unit
- 70 Watt DC
- This stator increase power output significantly
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connectors included
- Rubber grommet included
- All products shipped are tested
20% MORE OUTPUT OVER STOCK, WORKS WITH ALL OTHER OEM COMPONENTS.
All item pictures are accurate; if in doubt, do not hesitate to compare our item to your original part.
Specifications:
Dimensions:
Interior diameter: 29 mm
Exterior diameter: 77 mm
Thickness: 21 mm
Length of wires stator to grommet: 120 mm
Length of wires grommet to plug: 520 mm
Length of pickup coil’s wire to grommet: 90 mm
Other specifications:
Number of wires: 4
Number of plugs: 1
Number of pins: 4
Number of poles: 12
Wire to wire resistance:
Alternator: Yellow to Yellow = 0.4 ohms +-20%
Alternator: Yellow to ground = O.L
Pickup: Red to Green = 130 ohms +-20%
Warning:
Battery condition is important. No stator can make up for a bad or weak battery. If in doubt charge your battery and have it load tested, or simply replace it. ALWAYS START WITH A FULLY CHARGED BATTERY !
